X-Ray Equipment

Description

Model	CM-W1
Application	Adjustable with manual control knobs, exclusive use for radiography
Max. operating voltage	150 kVp
Max.field size	45 * 45cm at SID 100cm
Min. field size	Less than 1 * 1cm at SID 100cm
Light projection	More than 160 Lux at SID 100cm
Light source	24 VAC, 150 W, Halogen lamp
Lamp timer	Push button type 30 seconds electric timer
Inherent filtration	1.5 mmAl equivalent
SID scale	100, 150 and 200cm
Field coverage scale	13, 18, 20, 24, 28, 30, 35 and 43cm
Electrical requirement	24VAC, 7A
Dimensions	185(W) * 200(D) * 186(H) mm
Weight	Approx. 6.2kg

Model	CM-W2
Application	Adjustable with manual control knobs, exclusive use for radiography
Max. operating voltage	150 kVp
Max.field size	45 * 45cm at SID 100cm
Min. field size	Less than 1 * 1cm at SID 100cm
Light projection	More than 160 Lux at SID 100cm
Light source	24 VAC, 150 W, Halogen lamp
Lamp timer	Push button type 30 seconds electric timer
Inherent filtration	1.5 mmAl equivalent
SID scale	100, 150 and 200cm
Field coverage scale	13, 18, 20, 24, 28, 30, 35 and 43cm
Electrical requirement	24VAC, 7A
Beam source	Centering bucky device (optical power(mw) : < 1(Tc=25’c)
SID ruler	Tube-200cm (78inch)
Dimensions	185(W) * 200(D) * 192(H) mm
Weight	Approx. 6.5kg

Vertical Column	counter weight balance system, Floor mounted
Vertical Travel	Approximate 120, center to floor distance 50-165 above floor level.
Front Plate to Film distance	Approximate 3
Inherent Filteration of Front Plate	Less than 0.5 Al. eq.at 100kVp
Vertical Locking System	Electromagnetic lock, DC 24V
Cassette Loading	Left or Right loading
Bucky Device Unit	Reciprocating : Standard : Solenoid Option : Motor Film Formats : Up to 1417″(3543) Grid : Standard : Bucky 103LPI 10:1 fd=40-72″ Option : Bucky 150LPI 10:1 fd=40-72″
Dimensions	580W 575D 1830H
Power requirements	110/220VAC, 50/60
Options	Bucky device for 15″ upward tilting
